These output functions belong to the monitoring signals on this page:
MON1 SPK Vol L
MON1 SPK Vol R
MON1 HP Vol L
MON1 HP Vol R
MON2 SPK Vol L
MON2 SPK Vol R
MON2 HP Vol L
MON2 HP Vol R
For the monitoring signals 1 to 4, you can select the
Monitor is Mono
check box, if the monitoring signal is mono.
The
TB SPK
signal is always mono.
For the monitoring signal 1 (Speaker and Headphone), you can decide what happens when a CUE signal (PFL) is available.
If nothing is selected, no PFL signal will be available on this monitoring signal. Select the
Cue Add
check box to mix the
CUE signal with the monitoring signal. Select the
Cue Split
check box to assign the CUE signal to the left channel and
the monitoring signal to the right channel. You can also adjust the ratio between the PFL signal and the monitoring signal
with one of the encoders next to the central OLED display. To do this, follow these steps:
1. On the
Console
tab, on the central module, select one of the keys 9 to 12, the
Key Functions
window opens.
2. In the
Key Functions
window, double-click on
Monitor Functions
.
3. Drag the
Potentiometer
function to the
Function
entry in the
Key Options
area.
4. In the
Potentiometer
list, select
CUESPLIT
.
5. In the
Encoder
list, select one of the encoders -
F1
-upper encoder,
F2
-lower encoder.
If you press the configured key on the 52-1010 central module, you can use the encoder to change the attenuation of the
monitoring signal. Default value is set to -20 dB, this can be increased to off.In the
Additional Options
area, you
can change the
MON1 CUESPLIT Potentiometer Default Value
to values between -101 dB and 0 dB.
To dim the volume (-20 dB) of the monitoring signals 1 or 2, you can assign a logic source. Click the button, next to
the
DIM Condition
box. The
Logic Sources
window opens. Select a logic source from the list and click assign.
To mute the monitoring signals 1, you can assign a logic source. Click the button, next to the
MUTE Condition
box. The
Logic Sources
window opens. Select a logic source from the list and click assign.
To select the main input source for the monitoring busses, you have to assign a
audio signal. To do this, follow these steps:
1. On the main page, on the TFT/Touch Display of the 52/DX, tap on
Selector
.
2. On the bottom of the TFT/Touch Display, select the monitoring bus.
3. In the
Selector Sources
area, on the TFT/Touch Display, tap on the
signal source to assign it to the monitoring bus.
