In this list, all available default TFT views are
shown. Select a default view from the list. (For
differences between the default views see Default
views table)
Select the check box in front of the system
message to enable it on the TFT/Touch Display.
Shows the generated number of the selected key:
<name of fader module>.Key<key number on this
module>
Shows the assigned key function.
To change the default key function of a key, follow
these steps:
1. Select a key on the console view.
2. In the
View
menu, select
Key Functions
.
The
Key Functions
window opens.
3. In the
Key Functions
window select a Key
Function from the list and click
Select
.
Enter a name for the key. This name will be shown
in the Console View and will be available for the
label print feature.
Depending on the selected key function, you can
define here, with which color the key shall light up
according to the lamp source.
On
is the color if the
function is enabled,
Off
if the function is in
inactive condition. For the last case, mostly the
Off
option is used, for example the key does not
light up. Depending on the selected key function,
you find also different names in the
Lamp Source
column, for example
Standby
,
Available
,
Busy
,
Owned
,
Layer A
,
Layer B
or the name
of the selected
lamp source
.
You can define the colors red and yellow. You can
define flashing colors for the keys. Select the
check box, in the
Colors
area.
To change the logic source for a color, select an
entry in the
Lamp Source
column and click
Source
. The
Logic Sources
window opens. In
the
Logic Sources
window, select a logic
source from the list and click
Assign
.
Momentary
- The function is enabled as long as
the key is pressed.
Toggle
- This key is stay put.
Timed Toggle
- This key is stay put (short press)
or spring return (long press).
