Chapter 3: Installing the Micronics C400
26
Figure 3-2: Installing a CPU (Boxed version)
1
2
3
4
3
Install to
system board
CPU Installation (Boxed version)
A boxed version of the CPU is offered through Intel. This
packaging uses an active cooling fan. The mounting
hardware is described below. For detailed instructions,
please refer to the documentation that is supplied with
your CPU.
NOTE: Make sure the CPU speed is set correctly (refer to
Chapter 2: Jumper and Connector Settings).
