Micronics C400 System Board Manual
Chapter 3: Installing the Micronics C400
30
Installing an AGP Peripheral Card
The Micronics C400 AGP slot can accommodate all AGP
peripherals that meet the Intel AGP bus specifications.
Follow the steps below to install an AGP card:
1. Turn the computer system off and remove its cover.
2. Locate the AGP slot (J12) and remove the slot cover.
3. Insert the card with the bottom edge level to the slot.
Never insert the card at an angle.
4. Carefully push the card straight down, making sure
the card is fully inserted.
5. Replace the screw which holds the card in place.
6. Replace the computer cover.
7. Refer to the AGP card’s documentation for addi-
tional instructions regarding installation and soft-
ware drivers.
Figure 3-6: Installing an AGP Peripheral Card
