Micronics C400 System Board Manual
52
UART2 Mode
The second serial port offers the following Infrared inter-
face modes: Standard, HPSIR: IrDA-compliant serial in-
frared port, and ASK-IR: Amplitude shift keyed infrared
port. Standard mode is the default.
Onboard Parallel Port
Select an address and interrupt for the physical parallel
(printer) port.
Onboard Parallel Mode
Select an operating mode for the onboard parallel (printer)
port. Select SPP (default) unless your hardware and soft-
ware require one of the other modes offered in this field.
ECP Mode Use DMA
Select a DMA channel for the port. The default setting is
channel 3.
Chapter 4: The BIOS Setup Utility
