OPERATOR’S MANUAL
PM200, 200E and 250 Planter Monitors
11001-1444-200702
ALARMS / 38
Figure 29
Row Failure Display
ALL ROWS FAILURE
An All Row Failure alarm is a unique alarm identifier (8 chirps) that
differentiates from all other alarms and triggers when no seed flow is
detected from any row unit when ground speed is detected (Figure 30).
Typical scenarios to activate an All Row Failure alarm:
1. Tractor is stopped while planter is in the ground.
2. Tractor is operating with planter lifted.
3. Normal “end of run” turn around.
Figure 30
All Rows Failure Display
