OPERATOR’S MANUAL
PM200, 200E and 250 Planter Monitors
11001-1444-200702
ALARMS / 39
HI/LOW POPULATION WARNING
The Hi and Low population alarms trigger when seed flow drops below the
population alarm limit set on the Limits Setup screen. The alarm display will
beep and flash on the screen briefly indicating row units are over or under
the desired population (Figure 31). The Operate (Main) screen will display
the row unit over or under population symbol until corrected, an All Rows
Failure occurs, or sensor mechanical problems are fixed.
Figure 31
Population Limit Warning Display
SHAFT SPEED LOW/HI LIMIT WARNING
Alarm sounds when any shaft speed exceeds or falls below the value
entered for Shaft Speed Lo or Hi Limits in the Setup mode. Alarm can be
silenced by pressing Alarm key, but will re-activate if problem is not
resolved.
Figure 32
Shaft Speed Limit Warning Display
2 4 6 8
2 4 6 8
LOW SHAFT SPEED
HI SHAFT SPEED
