Technical specifications Performance specifications
XBee/XBee-PRO® S2C ZigBee® RF Module
16
Performance specifications
The following table describes the performance specifications for the devices.
Specification
XBee ZigBee S2C
XBee-PRO
ZigBee S2C XBee ZigBee S2D
Indoor/urban
range
Up to 60 m (200 ft)
Up to 90 m
(300 ft)
Up to 60 m (200 ft)
Outdoor RF line-
of-sight range
Up to 1200 m (4000 ft)
Up to 3200
m (2 mi)
Up to 1200 m (4000 ft)
Transmit power
output (maximum)
6.3 mW (+8 dBm), boost mode
3.1 mW (+5 dBm), normal mode
channel 26 max power is +3 dBm
63 mW (+18
dBm)
6.3 mW (+8 dBm) channel
26 max power is +1 dBm
RF data rate 250,000 b/s
Receiver
sensitivity
-102 dBm, boost mode
-100 dBm, normal mode
-101 dBm
-102 dBm, boost mode
-100 dBm, normal mode
Power requirements
The following table describes the power requirements for the XBee/XBee-PRO ZigBee RF Module.
Specification
XBee ZigBee S2C
XBee-PRO ZigBee
S2C
XBee
ZigBee S2D
Adjustable power Yes
Supply voltage 2.1 - 3.6 V 2.2 - 3.6 V for programmable
version
2.7 - 3.6 V 2.1 - 3.6 V
Operating current
(transmit)
45 mA (+8 dBm, boost mode) 33 mA (+5
dBm, normal mode)
120 mA @ +3.3 V,
+18 dBm
45 mA
Operating current
(receive)
31 mA (boost mode)
28 mA (normal mode)
31 mA 31 mA
Power-down
current
< 1 µA @ 25°C < 3 uA @ 25°
C
General specifications
The following table describes the general specifications for the devices.
Specification
XBee ZigBee S2C
XBee-PRO ZigBee S2C XBee ZigBee S2D
Operating frequency
band
ISM 2.4 - 2.5 GHz
Form factor through-hole, surface-mount surface-mount

Digi XBee Specifications

General

Operating Frequency	2.4 GHz
RF Data Rate	250 kbps
Model	XBee S2C
Category	Control Unit
Operating Voltage	2.1 to 3.6V DC
Operating Temperature	-40 to +85 °C
Interface	UART
Dimensions	24.38 x 27.61 x 9.14 mm
