Digi XBee User Manual

AT commands I/O settings commands
XBee/XBee-PRO® S2C ZigBee® RF Module
240
Parameter range
0, 1, 3 - 5
Parameter Description
0 Unmonitored digital input
1 Output 50% duty cycle clock at 32.787 kHz
3 Digital input, monitored
4 Digital output, default low
5 Digital output, default high
Default
0
P2 (DIO12 Configuration)
Set the configuration options for the DIO12 line of the RF device.
Parameter range
Parameter Description
0 Unmonitored digital input
1 SPI_MISO
3 3- Digital input, monitored
4 4- Digital output, default low
5 Digital output, default high
Default
0
P3 (DIO13/DOUT Configuration)
Set or read the configuration options for the DIO13 line of the RF module.
Parameter range
0, 1, 3 - 5
Parameter Description
0 Unmonitored digital input
1 Data out for UART

Digi XBee Specifications

General

Operating Frequency	2.4 GHz
RF Data Rate	250 kbps
Model	XBee S2C
Category	Control Unit
Operating Voltage	2.1 to 3.6V DC
Operating Temperature	-40 to +85 °C
Interface	UART
Dimensions	24.38 x 27.61 x 9.14 mm
