Data Sample Rx Indicator frame - 0x92
Description
When the device receives an I/O sample frame from a remote device, it sends the sample out the
serial port using this frame type (when AO=0). Only modules running in API mode will send I/O
samples out the serial port.
Format
The following table provides the contents of the frame. For details on frame structure, see API frame
format.
Frame data
fields Offset Description
Frame type 3 0x92
64-bit source
address
4-11
MSB first, LSB last. The sender's 64-bit address.
16-bit Source
network
address
12-13 MSB first, LSB last. The sender's 16-bit address.
Reserved 12-13 Reserved, will be 0xFFFE.
Receive
options
14
Bit field:
0x01 = Packet acknowledged
0x02 = Packet is a broadcast packet
Ignore all other bits
Number of
samples
15
The number of sample sets included in the payload. Always set to 1.
Digital
channel mask
1
16-17 Bitmask field that indicates which digital I/O lines on the remote have
sampling enabled, if any.
Analog
channel mask
2
18 Bitmask field that indicates which analog I/O lines on the remote have
sampling enabled, if any.
Digital
samples (if
included)
19-20
If the sample set includes any digital I/Olines (Digital channel mask > 0),
these two bytes contain samples for all enabled digital I/O lines. DIO lines
that do not have sampling enabled return 0. Bits in these two bytes map
the same as they do in the Digital channel mask field.
1
N/A N/A N/A CD/DIC12 PWM/DI011 RSSI/DIO10 N/A N/A
CTS/DI07 RTS/DI06 ASSOC/DI05 DI04 AD3/DI03 AD2/DI02 AD1/DIO1 AD0/DIO0
2
Supply Voltage N/A N/A N/A AD3 AD2 AD1 AD0
