Digi XBee User Manual

AT commands I/O settings commands
XBee/XBee-PRO® S2C ZigBee® RF Module
244
Parameter Description
2 Analog input, single ended
3 Digital input
4 Digital output, low
5 Digital output, high
6
Packet trace interface enable. Must be set along with P9= 6 to output traces for OTA
sniffing.
Default
0
D2 (AD2/DIO2 Configuration)
Select or read the function for AD2/DIO2 (pin 18).
Parameter range
0 - 5
0 - 1
Parameter Description
0 Unmonitored digital input
1 SPI_CLK
for through-hole devices
2 Analog input, single ended
3 Digital input
4 Digital output, low
5 Digital output, high
Default
0
D3 (AD3/DIO3 Configuration)
Select or read the function for AD3/ DIO3.
Parameter range
0 - 5
Parameter Description
0 Unmonitored digital input

Digi XBee Specifications

General

Operating Frequency	2.4 GHz
RF Data Rate	250 kbps
Model	XBee S2C
Category	Control Unit
Operating Voltage	2.1 to 3.6V DC
Operating Temperature	-40 to +85 °C
Interface	UART
Dimensions	24.38 x 27.61 x 9.14 mm
