Digi XBee User Manual

AT commands I/O settings commands
XBee/XBee-PRO® S2C ZigBee® RF Module
246
Default
1
D8 (DIO8/DTR/SLP_RQ)
Set or read the DIO8/DTR/SLP_RQ pin configuration (TH pin 9/SMT pin 10).
Parameter range
0, 1, 3 - 5
Parameter Description
0 Unmonitored digital input
1 Input to sleep and wake device
3 Digital input
4 Digital output, low
5 Digital output, high
Default
N/A
D9 (DIO9/ON_SLEEP)
The DIO9/ON_SLEEP pin configuration (pin 13 for through-hole, pin 26 for surface-mount).
Parameter range
0, 1, 3 - 5
Parameter Description
0 Disabled
1
ON/SLEEP output
2 N/A
3 Digital input
4 Digital output, low
5 Digital output, high
Default
1
LT (Associate LED Blink Time)
Set or read the Associate LED blink time. If you use the D5 command to enable the Associate LED
functionality (DIO5/Associate pin), this value determines the on and off blink times for the LED when
the device has joined the network.

Digi XBee Specifications

General

Operating Frequency	2.4 GHz
RF Data Rate	250 kbps
Model	XBee S2C
Category	Control Unit
Operating Voltage	2.1 to 3.6V DC
Operating Temperature	-40 to +85 °C
Interface	UART
Dimensions	24.38 x 27.61 x 9.14 mm
