Digi XBee User Manual

API Operation Frame descriptions
XBee/XBee-PRO® S2C ZigBee® RF Module
190
Example
If you press the commissioning pushbutton on a remote device with 64-bit address
0x0013A200407402AC and a default NI string sends a Node Identification, all devices on the network
receive the following node identification indicator:
A remote device with 64-bit address 0x0013A200407402AC and a default NI string sends a Node
Identification, all devices on the network receive the following node identification indicator:
If you press the commissioning button on a remote router device with 64-bit address 0x0013A200
40522BAA, 16-bit address 0x7D84, and default NI string, devices on the network receive the node
identification indicator.
Frame data fields Offset Example
Start delimiter 0 0x7E
Length
MSB 1 0x00
LSB 2 0x20
Frame type 3 0x95
64-bit source address MSB 4 0x00
5 0x13
6 0xA2
7 0x00
8 0x40
9 0x52
10 0x2B
LSB 11 0xAA
16-bit source
network address
MSB 12
0x7D
LSB 13
0x84
Receive options 14 0x02
Source 16-bit address 15 0x7D
16 0x84

Digi XBee Specifications

General

Operating Frequency	2.4 GHz
RF Data Rate	250 kbps
Model	XBee S2C
Category	Control Unit
Operating Voltage	2.1 to 3.6V DC
Operating Temperature	-40 to +85 °C
Interface	UART
Dimensions	24.38 x 27.61 x 9.14 mm
