Digi XBee User Manual

API Operation Frame descriptions
XBee/XBee-PRO® S2C ZigBee® RF Module
202
Frame data fields Offset Example
LSB 2 0x16
Frame type 3 0xA0
64-bit source (remote) address MSB 4 0x00
5 0x13
6 0xA2
7 0x00
8 0x40
9 0x3E
10 0x07
11 0x50
16-bit destination address 12 0x00
13 0x00
Receive options 14 0x01
Bootloader message type 15 0x52
Block number 16 0x00
64-bit target address 17 0x00
18 0x13
19 0xA2
20 0x00
21 0x40
22 0x52
23 0x2B
24 0xAA
Checksum 25 0x66

Digi XBee Specifications

General

Operating Frequency	2.4 GHz
RF Data Rate	250 kbps
Model	XBee S2C
Category	Control Unit
Operating Voltage	2.1 to 3.6V DC
Operating Temperature	-40 to +85 °C
Interface	UART
Dimensions	24.38 x 27.61 x 9.14 mm
