Digi XBee User Manual

API Operation Frame descriptions
XBee/XBee-PRO® S2C ZigBee® RF Module
204
Frame data fields Offset Example
LSB 2 0x13
Frame type 3 0xA1
64-bit source (remote) address MSB 4 0x00
5 0x13
6 0xA2
7 0x00
8 0x40
9 0x40
10 0x11
11 0x22
Source (updater) 16-bit address 12 0x33
13 0x44
Receive options 14 0x01
Number of Addresses 15 0x03
Address 1 16 0xEE
17 0xFF
Address 2 (closer hop) 18 0xCC
19 0xDD
Address n (neighbor of source) 20 0xAA
21 0xBB
Checksum 22 0x80

Digi XBee Specifications

General

Operating Frequency	2.4 GHz
RF Data Rate	250 kbps
Model	XBee S2C
Category	Control Unit
Operating Voltage	2.1 to 3.6V DC
Operating Temperature	-40 to +85 °C
Interface	UART
Dimensions	24.38 x 27.61 x 9.14 mm
