Digi XBee User Manual

API Operation Send ZigBee Cluster Library (ZCL) commands with the API
XBee/XBee-PRO® S2C ZigBee® RF Module
213
Frame data fields Offset Example
64-bit destination address MSB 5 0x00
6 0x13
7
0xA2
8
0x00
9
0x40
10
0x40
11
0x12
LSB12
0x34
16-bit destination
network address
MSB 13
0xFF
LSB 14
0xFE
Source endpoint 15 0x41
Destination endpoint 16 0x42
Cluster ID MSB 17 0x00
LSB 18 0x00
Profile ID MSB 19 0xD1
LSB 20 0x23
Broadcast radius 21 0x00
Transmit options 22 0x00
Data payload
ZCL frame header Frame control
23 0x00
Transaction sequence number 24 0x01
Command ID 25 0x00
ZCL payload Attribute ID 26 0x03
27 0x00
Checksum 28 0xFA

Digi XBee Specifications

General

Operating Frequency	2.4 GHz
RF Data Rate	250 kbps
Model	XBee S2C
Category	Control Unit
Operating Voltage	2.1 to 3.6V DC
Operating Temperature	-40 to +85 °C
Interface	UART
Dimensions	24.38 x 27.61 x 9.14 mm
