Digi XBee User Manual

API Operation Send Public Profile Commands with the API
XBee/XBee-PRO® S2C ZigBee® RF Module
218
Frame fields Offset
Example
64-bit destination
address
MSB 5 0x00
6 0x13
7 0xA2
8 0x00
9 0x40
10 0x40
11 0x12
LSB
12
0x34
16-bit destination
network address
MSB
13
0x56
LSB
14
0x78
Source endpoint 15 0x41
Destination endpoint 16 0x42
Cluster ID MSB
17
0x07
LSB
18
0x01
Profile ID MSB
19
0x01
LSB
20
0x09
Broadcast radius 21 0x00
Transmit options 22 0x00

Digi XBee Specifications

General

Operating Frequency	2.4 GHz
RF Data Rate	250 kbps
Model	XBee S2C
Category	Control Unit
Operating Voltage	2.1 to 3.6V DC
Operating Temperature	-40 to +85 °C
Interface	UART
Dimensions	24.38 x 27.61 x 9.14 mm
