Digi XBee User Manual

Regulatory information United States (FCC) XBee/XBee-PRO® S2C ZigBee® RF Module 279
Partnumber Type (description)
Gain
(dBi) Application*
Min.
separation
Required antenna cable loss
(dB)
Channels 11-
25 Channel 26
A24-F8NF Omni-directional (Fiberglass base station) 8.0 Fixed 2 m N/A N/A
A24-F9NF Omni-directional (Fiberglass base station) 9.5 Fixed 2 m N/A N/A
A24-F10NF Omni-directional (Fiberglass base station) 10.0 Fixed 2 m N/A N/A
A24-F12NF Omni-directional (Fiberglass base station) 12.0 Fixed 2 m N/A .9
A24-W7NF Omni-directional (base station) 7.2 Fixed 2 m N/A N/A
A24-M7NF Omni-directional (Mag-mount base station) 7.2 Fixed 2 m N/A N/A
A24-F15NF Omni-directional (Fiberglass base station) 15.0 Fixed 2 m 2.5 3.9
Panel antennas
A24-P8SF Flat Panel 8.5 Fixed 2 m 1 1.6
A24-P8NF Flat Panel 8.5 Fixed 2 m 1 1.6
A24-P13NF Flat Panel 13 Fixed 2 m 5.5 6.1
A24-P14NF Flat Panel 14 Fixed 2 m 6.5 7.1
A24-P15NF Flat Panel 15.0 Fixed 2 m 7.5 8.1
A24-P16NF Flat Panel 16.0 Fixed 2 m 8.5 9.1
A24-19NF Flat Panel 19.0 Fixed 2 m 11.5
12.1
Yagi antennas
A24-Y6NF Yagi (6-element) 8.8 Fixed 2 m .3 N/A
A24-Y7NF Yagi (7-element) 9.0 Fixed 2 m .5 N/A
A24-Y9NF Yagi (9-element) 10.0 Fixed 2 m 1.5 1.0

Digi XBee Specifications

General

Operating Frequency	2.4 GHz
RF Data Rate	250 kbps
Model	XBee S2C
Category	Control Unit
Operating Voltage	2.1 to 3.6V DC
Operating Temperature	-40 to +85 °C
Interface	UART
Dimensions	24.38 x 27.61 x 9.14 mm
