Page -21Digital Dream Standalone Motion Controller DDCS V3.1 DDCS V3.1 Users Manual
3、Z Coordinate
This column shows the current coordinate value of Z. The display range is
-99999.999~+99999.999 in mm;
4、A CoordinateThis section has no definition in the 3-axis
This column shows the current coordinate value of A. The display range is
-99999.999~+99999.999 in mm;
5、Current Operation
When the controller runs the G code file, it will show the current operation line number and
coordinates. When the operation state is READY, it will show nothing
6、Page
The page shows the current page. This controller has 3 pages, Main Page, File Page and Con-
figuration Page. Press Page button to move between the Pages.
7、Operation Window
This message window switches between 3 displays. It shows the prompt message of several
keys and the 2nd (second function)
The message displayed while in normal state is: Normal Mode.
The message displayed of the 2nd function status is:
X-: goto 0, Y-: zero, Z-: home, A-: probe, Pause: goto break
If you now click X-, the machine will move to Zero. If you click A-, the probe function will be
activated. If you click Y-, all coordinates will be set to Zero. If you click Z-, the machine will home.
If you click Start, the Start Line window appears and you can enter the G-code line you want to
start from. Click on Pause to enter the breakpoint CONT Callback Function.
Tip:
You need to click these functions twice to activate them (first click is “select, second click
is “activate”.
Tip:
When you are in an Editing Window, you can insert values by using the following keys:
X-: moves the cursor left
X+: moves the cursor right
Y-: decrease the value
Y+: increases the value
Z-: Enter
Z+: Cancel
8 Coordinate System
With the control panel it is very easy to control your Machine Coordinates and Work Offset
Coordinates. Click FRO/SRO/SJR (from now on only called FRO) 6 times until the coordinate
system is highlighted. Here you can display G54 to G59 and MACH (Machine Coordinates) by
clicking A+ and A-
