Digital Dream Standalone Motion Controller DDCS V3.1 DDCS V3.1 Users Manual
Page -43
Figure 3-36 Press Modify Key to edit the value
Figure 3-37 Press A+ and set the S value as the current spindle speed
3.3.4.6 Select G coordinate system
Under “READY”, press the key till the Coordinate System is highlighted. It will display
G54, ….G59 or MACH (Machine Coordinates).
Use and to choose your desired Coordinate System. Position values will be
displayed for X, Y, Z and A. The Enter key confirms the Coordinate System you chose.
Tab
A
+
A
SELECT
A
-
PROBE
MODIFY
