Digital Dream Standalone Motion Controller DDCS V3.1 DDCS V3.1 Users Manual Page -4
1.2 DDCS V3.1 Brief technical feature:
1) 16 photoelectric isolated digital inputs,3 photoelectric isolated digital outputs;
2) 3.1 Version enhanced Algorithm,support soft interpolation,fixed arc interpolation bug of
the old version;
3) Analog spindle control 0-10V spindle control (can be modified as PWM output);
4) 3-4 axes motor Control.Differential Pulse and direction output signal,Max.500Khz per
axis;
5) ARM9 main control chip,FPGA core algorithm chip;
6) 5 inches TFT screen, resolution ratio: 480x272,17 operation keys;
7) The Power Supply for the controller is 24VDC, minimum Current is 0.5A;
8) The Power Supply for IO Port is 24VDC,minimum current is 0.5A;By the IO power
supply,system already supply the power for IO ports.So no need the external power supply for
IO port anymore;
9) USB flash disk support for G code file input,no size limited of the G-code file ;
10) Support standard MPG;
11) Jog function for each axis (continuous, step, defined distance);Customer can define the
distance;
12) Support the operation of quickly specify the running position;
13) Support for “Power Cut” recovery. Data is automatically saved;
14) Backlash compensation, Tool compensation
1） Control System Unit is compatible with Metric Units and Imperial Units;
2） MPG and extended Keyboard can also control and edit the controller system；
3） Add new function of “Try cutting”(handwheel guiding) and “Single-stage processing
mode” ;
4） 3 kinds Probing Modes:Fixed Position of tool sensor,Floating Position of the tool
sensor,Rectangular block Sensor;
5）Enhanced the software,added a lot of parameters,Optimal Design and algorithm,makes
the new version more strong functions and steady;
6） The Option Language of the system is Chinese/English/Russian.
7) Version 3.1 cited the new circuit design and metal box,which can avoid the noise a lot.
DDCS V3.1 New features compared to previous version:
