Digital Dream Standalone Motion Controller DDCS V3.1 DDCS V3.1 Users Manual
Page -33
Figure 3-17 Tool path display, processing completed
3.3.2.2 Breakpoint operation
Note：When you click , it will automatically produce a breakpoint. In case of power
outage, it will also automatically record the breakpoint. As the Figure 3-18 shows, it begins
processing from the 255
th
line at this time. Figure 3-18 shows the display under the “goto break”
status and the display shows the file name.
Press to enter the second-Function(2nd) mode. Click to enter the breakpoint
operation. The controller will run from the last recorded breakpoint.
PAUSE
PAUSE
Shift
Figure 3-16 Tool path display after processing 1/3 of the file
