Digital Dream DDCS V3.1 User Manual

Page -6Digital Dream Standalone Motion Controller DDCS V3.1 DDCS V3.1 Users Manual
5'' Screen
17 Buttons
The front panel consists of 17 user keys and the 5’’ (480*272) LCD.
At the back side of the controller,there are USB Disk interface,MPG Port,Main Port and exter-
nal Start/Pause/Estop interface.
For convenient connections we supply a 3 layer wiring terminalfor main port.
We also supply a DB-15 Male plug for MPG connection.
The 8 screws are to fix the wiring ternimal and controller.
The USB Stick is for the transfer of the G-code file.
Figure1-3 Front panel
Figure 1-4 Back side of the controller and the accessories

Digital Dream DDCS V3.1 Specifications

General

Brand	Digital Dream
Model	DDCS V3.1
Category	Controller
Language	English
