INSIGHT 4K LASER User Manual
1.3.3. Bottom of the projector
1. Four adjustable feet
2. Six M6 holes for ceiling mount (set A)
The screws should not penetrate more than 15 mm into the body of the projector.
3. Handles for safe carriage
4. Six M6 holes for ceiling mount (set B)
The screws should not penetrate more than 15 mm into the body of the projector.
1
2
3
4
2
4
4
3
2
1
1
1
2
3
4
2
4
4
3
2
Page 17 of 65
