INSIGHT 4K LASER User Manual
6.4. Specifications
Projection method 3 chip DLP Cinema® method
1.38-inch Darkchip DMD
Panel resolution 4096 x 2160
Light source Laser
Contrast ratio 2000:1 with DCI specified color representation
Lens adjustment function Motorized lens shift (vertical/horizontal), motorized zoom, motorized focus, douser
Signal input ports
External Control RS-232C (D-sub 9pin) x 1
GPIO port (D-sub 37 pin) x 1
Service terminal (stereo mini jack) x 1
3D CTL (D-sub 15 pin) x 1
USB (Type A) x 1
Remote interlock port x 1
Power supply voltage AC 200 to 240 V, 50/60 Hz single phase
Power consumption 1600 W
Cooling method Cooling fluid system, Cooling air system
Installation Orientation: Desktop/front, Desktop/rear, Ceiling/front, Ceiling/rear
Net weight 67 kg (Excluding lens)
700 mm (W) x 935 mm (D) x 314.2 mm (H) (Does not including protruding portions, includes foot.)
Environment Operating temperature: 10 to 40°C
Operating humidity: 10 to 85% (non-condensing)
Storage temperature: -10 to 50°C
Storage humidity: 10 to 85% (non-condensing)
Operating altitude: 0 to 3000m/9800 feet (1600m/5500 feet to 3000m/9800 feet: Set “Fan Speed Mode” to “High
(Note 1) The value is typical.
Note that these specifications and design can change without prior notice
.
Page 56 of 65
