Important Information
Symbols used in the User Manual
LASER WARNING: this symbol indicates that there is a potential hazard of eye exposure to laser radiation unless the
instructions are closely followed.
ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical shock unless the instructions are
closely followed.
WARNING: this symbol indicates that there is a danger of physical injury to yourself and/or damage to the equipment
unless the instructions are closely followed.
NOTE: this symbol indicates that there is some important information that you should read.
Specifications are subject to change without notice.
Electrical and physical specifications
Mains Voltage 200-240 VAC
50-60 Hz (single phase)
Operating Temperature 0°C to 35°C
Storage Temperature -20°C to 60°C
Operating Humidity 20% to 90% non-condensing
Weight 63 kg (138.9 lb) without lens
Power Consumption 1608 W
Thermal Dissipation 5027 BTU/hr
Non-accessible laser parameters
Wavelength
435 - 462 nm
Laser Power for classification < 330 mW
Total internal power < 35 W
Apparent Source Size < 10 mm at aperture
Divergence ≤ ± 7.3 - 28°, lens dependent
Mode of operation CW
Modulation, due to frame rate 23 - 192 Hz
Page 2 of 65
