Digital Projection Insight Laser 4K - Adjusting the Position of the Projected Screen (Lens Shift)

INSIGHT 4K LASER User Manual
3.4.2. Adjusting the position of the projected screen (Lens shift)
1) Press the MENU button.
2) Press the LEFT/RIGHT button to display “Configuration” on the LCD screen.
3) Press the DOWN button.
4) Press the LEFT/RIGHT button to display “Lens Control” on the LCD screen.
5) Press the DOWN button.
The screen (“Lens Position”) to adjust the position of the projected screen is displayed.
6) Press the UP/DOWN/LEFT/RIGHT button.
The position of the projected screen moves in the selected direction.
7) Press the EXIT button when adjustment is complete.
The display will return to a menu one level above (where “Lens Control” is displayed).
Page 28 of 65
