INSIGHT 4K LASER User Manual
4.4. Configuration
Please request your dealer/distributor to perform the settings.
4.4.1. Light Setup
Adjusts the light source brightness (output). This setting is the fraction based on taking the maximum value of light source brightness as
100%.
← Adjusts the output power value (%).
4.4.2. Lens Control
Adjust the position, size, and focus of the projected screen.
Press the ENTER button to switch the display between “Lens Position” and “Focus Zoom” adjustments. Press the EXIT button to return to a
menu one level above.
Adjusts the position of the projected screen.
The projected screen moves in the selected direction as you press the UP/DOWN/LEFT/RIGHT button.
Adjusts the size (Zoom) and focus (Focus) of the projected screen. Press the UP/DOWN
button to adjust the focus.
Press the LEFT/RIGHT button to adjust the size of the projected screen.
Focus Zoom
Lens Position
Adjust
Page 40 of 65
