INSIGHT 4K LASER User Manual
4.2. Table of adjustment menus
Menus in parentheses are menus for our service personnel. Normally, these menus cannot be used.
Main menu Submenu Description
Reference
Title Select
“Title Memory Name”
Selects the title of the signal to be projected.
42
TEST Pattern
Selects the test pattern to be projected.
42
Configuration
Light Setup
Adjust
Adjusts the light source brightness (output).
43
Lens Control Lens Position Adjusts the position of the projected screen. 43
Focus Zoom
Adjusts the size and focus of the projected screen.
43
Reset
(FactoryDefault)
Returns the settings to their default values. Selects between preset but-
tons and titles only, LAN settings only and all settings.
-
Filter Usage
Initializes the usage time of the air filter.
44
(Fan Usage)
Initializes the usage time of the fan.
-
(Light Usage)
Initializes the usage time of the light source.
-
(Phosphor)
Initializes the usage time of the phosphor.
-
(Diffuser)
Initializes the usage time of the diffuser.
-
(LCS) Initializes the usage time of LCS (Liquid Cooling System). -
(Douser Count)
Resets the number of times the douser has been used.
-
(Setup)
Douser Setup
Sets the douser open/close state.
-
Panel Key Lock
Locks the buttons on the projector’s control panel so that they cannot be
operated.
-
Auto Key Lock
Enables or disables Auto Key Lock.
-
3D Connector
Sets the signal input terminal for a 3D image system (3D terminal or
GPI/O terminal).
-
Off Timer
Sets the time until the projector power is turned off automatically.
-
Filter Message
Sets the time to display the message indicating the air filter replacement
cycle.
-
Silent Mode
Selects whether to use the status indicator (SYSTEM / LIGHT), buzzer,
indicators on the control panel and backlight.
-
Installation (Note)
(Option Slot)
Configures the device installed in slot A (only when the projector is in
standby mode).
-
(Orientation)
Sets the projection method and cooling fan operating mode.
-
Lens Type (Note)
Sets the type of lens (supports or does not support the lens memory func-
tion) attached to the projector.
44
Lens Calibrate (Note)
Performs calibration on lens that support the lens memory function (only
when the projector power is turned on).
44
Lens Center (Note)
Moves the lens shift position to the center (only when the projector power
is turned on).
44
(Baudrate)
Sets the PC control connector (RS-232) data transmission speed (bps).
-
(Date/Time)
Sets the date and time on the projector.
-
(NewRouterSetup)
Sets the router with the default settings when the router built-in the
projector has been replaced.
-
(Fan Speed Mode)
Sets the cooling fan operating mode.
-
(Service Adj.)
(Only when the projector is in standby mode)
This is used during shadow adjustment and lens mount adjustment (focus
balance adjustment).
-
(LD Calibrate)
Performs calibration of the light module when the light module has been
replaced (only when the projector power is turned on).
-
(Memory) Light
The content of the selected light memory (light output power value) can
be overwritten with the current settings.
-
Lens
The content of the selected lens memory can be overwritten with the cur-
rent settings.
-
(Lens FW Update)
This will be used to update the lens firmware in the future.
-
(Title Setup)
Preset Button
Preset Button 1–16
Sets the title to be assigned to the preset buttons (<1> to <8> buttons).
45
