54
151
Block-Number (abs) at event n. 2: this is the block number (absolute) to be used when the event occured that has been programmed
in Q.150. The allowed value goes from 0 (min) to 62 (max). Also allowed is the value 255; In this case, instead of using a new block
number, the former block number is used again.
0 - 62
152
Block-O! set (rel) at event n. 2: this is the block offset (relative) to be used when the event occured that has been programmed in Q.150.
The relative block offset is the number of blocks to add to the current block number in order to obtain the new block number. The
allowed value goes from 0 (min) to 62 (max).
0 - 62
153
Load-value is Units? - Is the parameter programmed in Q.150 for event counter 2 the number of units.
No / Yes
154
Load-value is Distance (in metres)? - Is the parameter programmed in Q.150 for event counter 2 the distance in metres?
No / Yes
155
Load-value is Wai" ng-Time (in seconds)? - Is the parameter programmed in Q.150 for event counter 2 the waiting-time in seconds?
No / Yes
156
Load-value is Cost of Fare? - Is the parameter programmed in Q.150 for event counter 2 the cost of the fare?
No / Yes
157
Load-value is Cost of Extra-Charge? - Is the parameter programmed in Q.150 for event counter 2 the cost of the extracharge?
No / Yes
158
Reload every Metre ? (if not: every Second) - Event Counter 2 must be reloaded every metre? If not then it will be reloaded every second.
The allowed answer is either: 0 (No: every second) or: 1 (Yes: every metre).
No / Yes
159
Act. Only Above cross-speed? (if not: Allw.) - Event Counter 2 should be activated only above the cross-speed? If not then it will allways
be activated. The allowed answer is either: 0 (No: always) or: 1 (Yes: only above).
No / Yes
160
Event Counter is momentarily suspended? - Event Counter 2 should be momentarily suspended? If not then it will be active. The allowed
answer is either: 0 (No: active) or: 1 (Yes: suspended).
No / Yes
COUNTER N. 3
161
Load-value Event-Counter n. 3: this is either the number of units, or the distance in metres, or the time in seconds, or the cost of the
fare, or the cost of the extra charges that should be counted for the tariff-block to be changed. The allowed value goes from 0 (min) to
65535 (max). The tariff-block to change to is to be programmed in Q.162.
0 – 65535
162
Block-Number (abs) at event n. 3: this is the block number (absolute) to be used when the event occured that has been programmed
in Q.161. The allowed value goes from 0 (min) to 62 (max). Also allowed is the value 255; In this case, instead of using a new block
number, the former block number is used again.
0 - 62
163
Block-O! set (rel) at event n. 3: this is the block offset (relative) to be used when the event occured that has been programmed in Q.161.
The relative block offset is the number of blocks to add to the current block number in order to obtain the new block number. The
allowed value goes from 0 (min) to 62 (max).
0 - 64
164
Load-value is Units? - Is the parameter programmed in Q.161 for event counter 3 the number of units?
No / Yes
165
Load-value is Distance (in metres)? - Is the parameter programmed in Q.161 for event counter 3 the distance in metres?
No / Yes
166
Load-value is Wai" ng-Time (in seconds)? - Is the parameter programmed in Q.161 for event counter 3 the waiting-time in seconds?
No / Yes
167
Load-value is Cost of Fare? - Is the parameter programmed in Q.161 for event counter 3 the cost of the fare?
No / Yes
168
Load-value is Cost of Extra-Charge? - Is the parameter programmed in Q.161 for event counter 3 the cost of the extra-charge?
No / Yes
169
Reload every Metre? (if not: every Second) - Event Counter 3 must be reloaded every metre? If not then it will be reloaded every
second. The allowed answer is either: 0 (No: every second) or: 1 (Yes: every metre).
No / Yes
170
Act. Only Above cross-speed? (if not: Allw.) - Event Counter 3 should be activated only above the cross-speed? If not then it will allways
be activated. The allowed answer is either: 0 (No: allways) or: 1 (Yes: only above).
No / Yes
171
Event Counter is momentarily suspended? - Event Counter 3 should be momentarily suspended? If not then it will be active.The allowed
answer is either: 0 (No: active) or: 1 (Yes: suspended).
No / Yes
COUNTER N. 4
172
Load-value Event-Counter n. 4: this is either the number of units, or the distance in metres, or the time in seconds, or the cost of the
fare, or the cost of the extra charges that should be counted for the tariff-block to be changed. The allowed value goes from 0 (min) to
65535 (max). The tariff-block to change to is to be programmed in Q.173.
0 - 65535
173
Block-Number (abs) at event n. 4: this is the block number (absolute) to be used when the event occured that has been programmed
in Q.172. The allowed value goes from 0 (min) to 62 (max). Also allowed is the value 255; In this case, instead of using a new block
number, the former block number is used again.
0 - 255
174
Block-O! set (rel) at event n. 4: this is the block offset (relative) to be used when the event occured that has been programmed in Q.172.
The relative block offset is the number of blocks to add to the current block number in order to obtain the new block number. The
allowed value goes from 0 (min) to 62 (max).
0 - 64
