E-21
English
Configuring the Heat Pump Heating System 6.1
Sets the duration of the individual steps during the
heating-down phase
1
... 24...
120
At all times
Sets the temperature difference between the two
steps in the heating-up phase
1 K
... 5 K ...
10 K
At all times
Sets the temperature difference between the two
steps in the heating-down phase
1 K
... 5 K ...
10 K
At all times
Activates the individual program for screed drying No
Yes
At all times
By activating this function, the difference between
flow and return flow is measured at the start of
defrosting. If the value is > 12 K, a fault is activated.
No
Yes
Air HP
By activating this function, a fault is activated if an
expected reduction in the flow temperature does
not take place
No
Yes
Air HP
After-sales service functions At all times
Displays the time to the next defrosting At all times
Setting for selecting the type of external sensor in
use.
NTC acc. to
DIN 44574
NTC acc. to
DIN Carel
Controller without
integrated display
After this function is activated, all of the display
segments will be activated for approx. 10 seconds.
No
Yes
At all times
Displays all the temperatures measured in the
heating system in compact form
At all times
Displays the statuses of all digital outputs in the
heating system in compact form
At all times
Displays the statuses of all digital inputs in the
heating system in compact form
At all times
Displays all the analogue values measured in the
cooling system in compact form
Cooling function
Displays all the digital inputs and outputs in the
cooling system in compact form
Cooling function
Activation of special functions Display
