E-9
English
Preconfiguring the Heat Pump Heating System 5.1
5 Preconfiguring the Heat Pump Heating System
The preconfiguration informs the controller about which
components are connected to the heat pump heating system.
Preconfiguration must be carried out before the system-specific
settings in order to show or hide menu items (dynamic menus).
The following table shows not only the menu structure and
explanations in the right-hand column, but also the
corresponding setting ranges. Values in bold print indicate the
factory settings.
The factory settings in the “Preconfiguration” menu correspond
to the integration diagram for a mono energy heat pump
(normally an air-to-water heat pump) with 1 compressor and a
heating circuit without DHW heating using the heat pump.
5.1 Menu
You can access the preconfiguration menu by:
Simultaneously pressing (approx. 5 seconds) the button
combination (ESC) and (MENUE).
Exit the preconfiguration via the button (ESC).
Abbreviations:
The following presettings must be carried out:
HP Heat pump
AW HP Air-to-water heat pump
BW HP Brine-to-water heat pump
WW HP Water-to-water heat pump
Preconfiguration of all system components for
dynamic menu structuring
Setting range Display
Monovalent (heat pump as sole heat
generator), mono energy (heat pump and
immersion heater), bivalent-parallel (heat
pump and boiler), bivalent-alternative (heat
pump or boiler), bivalent-regenerative (heat
pump or reg. heat source)
Monovalent
Mono energy
Bivalent-parallel
Bivalent-alternat.
Bivalent-regener.
Bivalent-regenerative,
with nonreversible HP
only
Has an additional heat exchanger with
supplementary connections for DHW
preparation been installed in the heat pump?
Yes
No
Reversible HP
AW HP
Has the system got an unmixed heating circuit? Yes
No
At all times
Has the system got a heating circuit 2 with a
controllable mixer?
No
Yes
At all times
Has the system got a heating circuit 3 with a
controllable mixer?
No
Yes
Heating circuit 2
Nonreversible HP
Nonbivalent system
Will the cooling function of the reversible heat
pump be used?
Yes
No
Reversible HP
Is a passive cooling controller connected to the
heating controller?
No
Yes
BW or WW HP
Nonreversible HP
Is a 2 or a 4-pipe system used for passive
cooling?
2-pipe system
4-pipe system
BW or WW HP
Nonreversible HP
Passive cooling function
Is DHW heating carried out by the heat pump? No
Yes
At all times
