【5-4】
F
RAME
● Remove Left and Right Fender.
Front Fender Installation
● Please reverse the Removal steps to install.
Rear Fender Removal
● Remove:
Seat
Rear rack
● Remove:
Pan head Screw [A]×6 (attach to luggage compartment)
Pan head Screw [B]×3 (attach to luggage compartment)
Machine Screw [C] ×6 (right×3, left×3, attach to footboard)
Rear Fender Installation
● Please reverse the Removal steps to install.
Radiator Removal
● Remove:
Front fender decoration
Headlight shade
A
C
B
E
