Dinli DL702 - Foot Board Removal; Headlight Assembly Removal

【5-5】
F
RAME
Tube Clip and Water Hose ×2 [A]
Cooling fan switch [B]
Cooler bracket bolts ×4
Cooler bracket
Radiator Protector Bolts ×4
Radiator Protector
Reservoir water hose [C]
Reservoir tank bolt ×2
Reservoir tank
Radiator Installation
● Please reverse the Removal steps to install.
Foot Board Removal
● Remove:
Machine Screw ×6 (attach to front & rear fender)
Hex Washer Face Bolt ×2 (attach to body decoration)
Foot Board Bracket Bolts [A] ×4
Foot Board
Headlight Assy Removal
● Remove:
Headlight Screws [A] ×3
Headlight Wire
Headlight
A
B
A
A
C
A
