【6-12】
E
NGINE
● Remove the movable drive face [2] by removing the bolt.
● Remove the movable driven face assembly by removing the bolt.
● Remove the drive belt.
● Remove the fixed drive face.
● Remove the front and rear output connectors.
● Remove the plate [1], clutch inner cover [2] with the clutch housing
and gasket.
