Operating Instructions RF-2000
22
(8) Set the terminal of cable connected to the plus pole in the screw at the plus
pole of the lamp and fix it with a knurled screw securely.
(9) Remount the light source chamber cover.
Warning:
When tightening the terminal at the plus pole with a
knurled screw, be sure to allow the cable to the plus pole
be bent.
If the plus pole is stretched by the cable, there occurs a
danger that the xenon lamp may be destroyed while being
lit. Besides, when tightening the knurled screw, be sure to
tighten by fingers. It is dangerous to use any tool such as
wrench.
