Operating Instructions RF-2000
72
8.3 Replacing the Fuse
Warning:
This instrument uses two of the following fuses. Be sure to replace
the fuses of the same type and capacity.
for power supply: 220-240 VAC
Part no. 706.072.0165221
250V 3.15AT
Replace the blown fuse according to the following procedure. Be sure to use a fuse
specified in the Accessories and Spare Parts list.
(1) Turn the power switch OFF.
(2) Disconnect the power cable from the power supply connector.
(3) Open the fuse holder cover with a regular screwdriver.
(4) Take out the fuse holder to this side.
(5) After replacing the fuse, push the fuse holder in with the arrow side faced
down.
(6) Close the fuse holder cover until it clicks.
