Operating Instructions RF-2000
59
7.2.2 Setting parameters and activating the remote control mode
Press the func key (or shift + func key) repeatedly, until the display indicates the
command:
EX(nm) EM(nm) Data
RS232C
Press the Enter key to display the commands for setting the parameters for RS-
232C.
The commands are shown as follows.
When pressing the func key, the display successively displays the commands in the
following order.
When pressing the shift + func key, the commands are indicated in the reverse
order.
Activating the Remote control mode:
EX(nm) EM(nm) Data
CONNECT
Then press the func key to set the baud rate:
EX(nm) EM(nm) Data
BAUD __
Then press the func key to set the data word size:
EX(nm) EM(nm) Data
DATA BITS __
Then press the func key to set the parity:
EX(nm) EM(nm) Data
PARITY __
Then press the func key to set the stop bit:
EX(nm) EM(nm) Data
STOP BIT __
(1) Activating remote control mode
EX(nm) EM(nm) Data
CONNECT
Press the Enter key. The RF-2000 is is now controlled from the external
equipment via the RS-232C interface.
In the remote control mode, the display of the RF-2000 indicates the
excitation wavelength, the emission wavelength and the emission intensity,
and RF-2000 outputs the analog signals of the emission intensity.
In this mode, any key input is disabled.
Please note:
When turning the power ON again, the remote mode is
activated. To release this mode, press the shift key and the CE
key simultaneously.
