7. Unlock Output (Blue wire on 3-pin harness):
1. 1 pulse: The unlock output pulses once.
2. 2 pulses: The unlock output pulses twice.
8. Lock Output (Green wire on 3-pin harness):
1. 1 pulse: The lock output pulses once.
2. 2 pulses: The lock output pulses twice.
9. OEM Alarm Disarm w/Trunk Release:
1. On: The Factory Alarm Disarm wire will pulse as programmed when the Trunk release output is acti-
vated.
2. Off: The Factory Alarm Disarm wire will not pulse when the Trunk release output is activated.
10. OEM Alarm Disarm Output (Green/Black wire, 24-pin harness):
1. With Unlock: In the default setting the factory alarm is disarmed any time the button(s) controlling Un-
lock is pressed and when remote start is activated.
2. Before Unlock: Output to disarm the factory alarm activates before unlock and when remote start is
activated.
3. Remote Start Only: Output disarms the factory alarm before remote start is activated.
11. OEM Alarm Disarm Pulses (Green/Black wire, 24-pin harness):
1. 1 Pulse: The OEM Alarm Disarm wire will pulse once per operation.
2. 2 Pulses: The OEM Alarm Disarm wire will pulse twice per operation.
12.
AUX 4 Output Type (Violet/Black on the 24-pin harness):
This wire provides a (-) 200mA output whenever the transmitter button(s) controlling AUX 4 is pressed.
This output can be programmed to provide the following types of outputs:
1. Validity: Output that will send a signal as long as the transmission is received.
2. Latched: Output that will send a signal when the AUX button is pressed and will continue until the same
button(s) is pressed again.
3. Latched, Reset with Ignition: Similar to the latched output, this type of output turns on the first time the
AUX button is pressed and turns off the next time the same button is pressed. This type of output ad-
ditionally stops and resets whenever the ignition is turned on and then off.
4. 30 (60 or 90) second Timed: Output that will send a continuous signal for 30, 60 or 90 seconds.
Note: All auxiliary channel timed outputs can be programmed using the Bitwriter® (1-90 seconds).
13. AUX 4 Linking:
1. Linking None: Feature not enabled.
2. Arm: When programming to validity or timed output this can be programmed to activate when arming
3. Disarm: When programming to validity or timed output this can be programmed to activate when
disarming
4. Remote Start: When programming to validity or timed output this can be programmed to activate when
remote starting with the transmitter.
14. AUX 5 Output Type (White/Black on the 24-pin harness): Validity (1)/Latched (2)/Latched Reset With
Ignition (3)/30(4),60 (5) And 90 (6) Sec Timed Output:
AUX 5 can be programmed for these output configurations. The unit is set to the default validity output.
To change the configuration, use the two-chirp setting to toggle through the different configurations. Refer
to feature 12 for additional detail.
15. AUX 5 Linking: None(1)/Arm (2), Disarm (3), Remote Start(4): Refer to feature 13 for additional detail.
16.
AUX 6 Output Type (Orange/Black on the 24-pin harness): Validity (1)/Latched (2)/Latched Reset With
Ignition (3)/30, 60 And 90 Sec Timed Output:
AUX 6 can be programmed for these output configurations. The unit is set to the default validity output.
To change the configuration, use the two-chirp setting to toggle through the different configurations. Refer
to feature 12 for additional detail.
17. AUX 6 Linking: None(1)/Arm (2), Disarm (3), Remote Start (4): Refer to feature 13 for additional detail.
