Wiring Diagram
5X05
Remote Start
10-pin Harness
Main 5-pin
Harness
Door Lock
3-pin
Harness
Light Flash
Polarity Jumper
(-/+)
Onboard
Thermistor
Temp Sensor
AUX/Shutdown/Trigger
24-pin Harness
RF Port/Control Center
Bitwriter/Directed SmartStart Port
Doubleguard Shock Sensor Port
D2D Port (for external
Directed interface Module)
Note: (+) or (-) light ash jumper needs to be installed for the appropriate
light ash polarity and is found taped to the outside on the main unit.
