Table of Zones
A zone is represented by the number of status LED flashes used by the system to identify a particular type of
input.
Zone Description Input Description
1 Trunk Pin 24-pin Harness Blue wire
2 Instant trigger: a heavier impact detected
by the Doubleguard Shock Sensor
Shock Sensor.
3 Door switch trigger 24-pin Harness Green or Violet wire
4 Instant trigger: For optional sensors Optional MUX port Green wire
5 Ignition trigger 10-pin Harness Pink wire
6 Hood Pin 24-pin Harness Gray wire
Troubleshooting: Alarm
Shock sensor doesn’t trigger the alarm:
1. Was the shock sensor adjusted before it was mounted? If so re-adjust the sensor.
2. Has the NPC system been triggered? If so, you hear 5 chirps when disarming. To check this, turn the
ignition key on and off to clear the NPC memory, and then retest the shock sensor. For a detailed
description of NPC, see Nuisance Prevention Circuitry section of the owners guide.
Door input does not immediately trigger full alarm. Instead, chirps are heard for the first 3 seconds:
• That’s how the progressive two-stage door input works! This is a feature of this system even if the door
is instantly closed again, the progression from chirps to constant siren continues.
Closing the door triggers the system, but opening the door does not:
• Have you correctly identified the type of door switch system? This happens often when the wrong
door input has been used.
System does not passively arm until it is remotely armed and then disarmed:
1. Is passive arming programmed ON?
2. Are the door inputs connected? Is the 24-pin harness Blue wire connected to the door trigger wire in
the vehicle? Either the 24-pin harness Green or Violet wire should be used instead.
Door input does not respond with the progressive trigger, but with immediate full alarm:
• Does the Status LED indicate that the trigger was caused by the shock sensor? (See Table of Zones
section of this guide.) The Doubleguard Shock Sensor, if set to extreme sensitivity, may be detecting
the door unlatching before the door switch sends its signal. Reducing the sensitivity can solve this
problem.
Door locks operate backwards.
• This unit has easily-reversed lock/unlock outputs. Recheck wire connections to see if you have re-
versed these.
