Menu 3 - Remote start
Menu
Item
One-chirp setting Two-chirp and up setting
1
Engine Checking Mode: Virtual Tach
Voltage (2), OFF (3), Tachometer (4)
2
Remote Start Runtime: 12 minutes
24 minutes (2), 60 minutes* (3)
3
Parking Light Output: Flashing
Constant
4
Cranking Time: 0.6 seconds
0.8 (2), 1.0 (3), 1.2 (4), 1.4 (5), 1.6 (6), 1.8 (7), 2.0 (8),
4.0 (9) second(s)
5
Activation Pulse: 1
2
6
2nd Ignition/Acc. Output: Ignition
Accessory
7
Acc. State During WTS (Wait-to-Start): Off
On
8
2nd Status Output: Normal
Rear Defogger: Latch 10 minutes. (2), Rear Defogger: Pulse (3)
9
Anti Grind Output: On
Off
10
Diesel Start Delay (in seconds): WTS (Wait-to-Start) input
Timed 15 (2), 30 (3), 45 (4) seconds*
11
Timer Mode Runtime: 12 minutes
3 (2), 6 (3), 9 (4) minutes*
12
Timer Mode Start Type: Timed Starts
Temp Starts
13
Short Engine Runtime (Turbo): 1 minute
3 (2), 5 (3), 10 (4) minutes
*Additional settings when using the Bitwriter
Menu 3 - Descriptions
1. Engine Checking Mode:
1. Virtual Tach: Battery voltage drop/rise during cranking determines when the starter output is released.
During runtime, constant voltage level is monitored to determine if the engine is running.
2. Voltage: Starter output during cranking is a programmed duration (Set in Cranking Time). During run-
time, constant voltage level is monitored to determine if the engine is running.
3. Off: Starter output during cranking is a programmed duration (Set in Cranking Time). The remote start
will keep the ignition/accessories active for the programmed runtime whether the engine is running or
not.
4. Tachometer: Tachometer input signal during cranking and runtime to determine when the starter output
is released and if the engine is running.
2. Run Time:
• 12/24/60 minutes: Sets engine runtime during normal remote start operations.
3. Parking Light Output (White wire on 5-pin harness):
1. Flashing: The lights will pulse on/off during remote start.
2. Constant: The lights will turn on solid during remote start.
4. Cranking Time:
• 0.6/0.8/1.0/1.2/1.4/1.6/1.8/2.0/4.0 seconds: Determines the starter output duration during
cranking for the ‘Voltage’ and the ‘Off’ Engine Checking Mode options.
5. Activation Pulse Count (White/Blue on 24-pin connector):
• 1/ 2 pulses: Sets the number of remote control commands received or Activation Input pulses required
to activate and de-activate remote start.
6. 2nd Ignition/Accessory Output (Pink/White on the 10-pin harness):
• This will allow the Pink/White wire to be used as a 2nd ignition or an accessory. The default is 2nd
ignition.
