DirecTV Advanced Installation Meter User Manual

1 Getting Started AIM User’s Manual
5
Getting To Know Your Meter
Features
Your AIM has the following features:
Connectors
1 IRD F connector
2 ODU F connector
3 Type A USB connector (Standard)
4 Type B USB connector (Mini)
5 Power input
Buttons
6 Softkeys
7 Navigation keypad
8 Alphanumeric keypad
9 Operation buttons
10 Power
Other
11 LCD display
Figure 1 Front View
11
10
9
8
7
6
5
4
3
2
1

DirecTV Advanced Installation Meter Specifications

General

Brand	DirecTV
Model	Advanced Installation Meter
Category	Measuring Instruments
Language	English
