1 Getting Started AIM User’s Manual
19
Technical Specifications
Frequency Range 250 MHz to 2150 MHz
Signal Level Range -10 dbm to -69 dbm
RF Input Connector Replaceable F-Type (2)
Input Impedance 75 ohm
Measurements Refer to the instructions in this manual.
LNB Power Supply 13 volts / 18 volts
SWiM Power Supply 21 volts
Communications USB flash drive (Linux format only)
Battery 8-cell 9.6 Volt 3.8 AH Rechargeable NiMH
Operating Temperature -25°F to 125°F (-29°C to 52°C)
Storage Temperature -40°F to 150°F (-40°C to 65°C)
Battery Charging Temperature 40°F to 100°F (5°C to 37°C)
Display 240
× 160 pixel backlit LCD
Weight 2 lbs, 8.6 oz (1150 g)
Dimensions 9.6”
× 4.6” × 2.3”
(244.4 mm
× 118 mm × 58.7 mm)
