DirecTV Advanced Installation Meter User Manual

3 Setting Up a Job AIM User’s Manual
35
Switch Type
To change the switch type for a job:
1 On the MODIFY JOB SETUP screen, use c or d to highlight Switch Type and
press SELECT to go to the SWITCH TYPE screen.
2 Use
c or d to highlight the type of switch for the job and press SELECT.
3 If the ODU configuration includes a 95° ODU and a 6 x 8 multiswitch or SWiM,
the 95 PORT CONNECTION screen appears. Use c or d to highlight the port
to which the 95° ODU is connected.
4 Press SELECT to return to the MODIFY JOB SETUP screen.
Tip: To exit without saving changes, press
CANCEL.
