1 Getting Started AIM User’s Manual
10
HOME Screen
The HOME screen lets you access the AIM’s main features. You can press the HOME
button at any time to access the HOME screen.
The HOME screen provides four softkeys that correspond to each of the main
features of the AIM:
SETUP: Lets you set up the information for a job. See “Setting Up a Job” on
page30.
INSTALL: Guides you through the steps for aligning and performing follow-up
Extended Installation Verification (EIV) for each ODU. See “Installing an ODU” on
page37.
EIV: Guides you through the steps for performing Extended Installation
Verification (EIV) at the ODU or another location to help you troubleshoot a
problem. See “Performing EIV” on page47.
TEST: Lets you run network tests to help you troubleshoot a problem with an
installation. See “Performing Other Network Tests” on page50.
Powering Your Meter
Power-On
To turn on the AIM, press and hold the POWER button until the backlight turns on.
The meter turns on, briefly displays a splash screen, and then displays the HOME
screen.
To start a job, press SETUP and follow the instructions in “Starting a Job” on
page31.
