AIM User’s Manual
iii
Installing an ODU 37
Aligning the ODU 37
Task A. Installation Setup 39
Task B. Coarse Azimuth Adjustment 40
Task C. Coarse Elevation Adjustment 40
Task D. Tilt Adjustment (95°, 3-LNB,
Slimline-5, and Slimline-5S (SWiM) ODUs Only) 41
Task E. Fine Elevation Adjustment
(Slimline ODUs Only) 41
Task F. Fine Azimuth Adjustment
(Slimline ODUs Only) 43
Performing EIV Following ODU Installation 45
Performing EIV 47
Performing Other Network Tests 50
Performing an In-Line Test 51
Performing a Satellite Tune Test 53
Performing a SWiM LF Power Test 57
Performing a Cable Resistance Test 59
Performing a Transponder Survey 61
