DirecTV Advanced Installation Meter User Manual

4 Installing an ODU AIM User’s Manual
38
The table below indicates which tasks need to be performed for each ODU. When
an installation includes two ODUs, you must perform the installation tasks for each
ODU. The AIM Install feature guides you through the tasks based on the selected
ODU.
When using the AIM to align an ODU, refer to the appropriate sections for
assistance:
 “Task A. Installation Setup” on page39
 “Task B. Coarse Azimuth Adjustment” on page40
 “Task C. Coarse Elevation Adjustment” on page40
 “Task D. Tilt Adjustment (95°, 3-LNB, Slimline-5, and Slimline-5S (SWiM) ODUs
Only)” on page41
 “Task E. Fine Elevation Adjustment (Slimline ODUs Only)” on page41
 “Task F. Fine Azimuth Adjustment (Slimline ODUs Only)” on page43
ODU Installation Tasks
ODU
Supported
Orbital Slots Setup
Coarse Azimuth
Adjustment
Coarse Elevation
Adjustment
Tilt
Adjustment
Fine Elevation
Adjustment
(Dither)
Fine Azimuth
Adjustment
(Dither)
3-LNB (18” x 20”) 101, 110, 119
999
9
95° 95
9999
Round (18”) 101
999
Slimline-3 99, 101, 103
999 99
Slimline-5 99, 101, 103, 110, 119
999
9
99
Slimline-3S (SWiM) 99, 101, 103
999 99
Slimline-5S (SWiM) 99, 101, 103, 110, 119
999
9
99
World Direct 95, 101
9999
