5 Performing EIV AIM User’s Manual
49
7 On the EIV RESULTS screen, review the results for all supported orbital slots and
SWiM channels (if applicable). A satisfactory result is indicated by 9. A problem
is indicated by X.
If 9 appears for all supported orbital slots, the ODU alignment is acceptable.
If X appears for an orbital slot, perform the following steps:
a Press REPEAT EIV to confirm the problem.
b If X appears again for one or more orbital slots, you can press EIV DETAIL to
determine which tests failed. Troubleshoot any failures following the
instructions provided by DIRECTV.
8 When you have finished reviewing EIV results on the EIV RESULTS screen, you
can press DONE to return to the HOME screen.
You also can press CHANGE LOC to perform EIV for another location.
Note: To change the location where you are
testing, press CHANGE LOC.
Note: On the EIV DETAILS screen, you can
press NEXT to view the details for another
orbital slot, or press BACK to scroll back
through the details to the EIV RESULTS screen.
