Chapter 2: Installation
Operation Manual: Evolution Series
7. Connect water bath outlet hose (5/8” I.D.) to the pump inlet using quick
disconnect coupling (lower connection on the bath and pump). Push the
coupling together until it clicks.
8. Make sure all hoses are installed fully onto fittings.
9. Place the hose clamps over fittings, with locking portion on right side of
fitting.
10. Tighten hose clamps snugly with pliers. Adjust position of unit so TCS does
not touch the Evolution bath, to avoid transmitting vibration.
Filling the Water Bath
1. Wipe the inside of water bath with damp cloth to remove any debris that
might lodge inside and damage pump.
2. Make sure the power switch on the upper rear panel of TCS-0200C is off
(press "0"). Plug the TCS into proper outlet.
3. Place temperature probe from TCS-0200C in bath location next to center
rear vessel.
4. Make sure bath drain valve is closed (handle should be perpendicular to
drain hose as shown in Figure 2-5).
5. Fill bath to midway between the top bath inlet fitting and the lower outlet
fitting (see Figure 2-7).
Priming the Pump
1. Attach a 3 ft. ( 1m) long x 5/8" (~16mm) ID drain tubing to drain valve.
2. Raise drain tubing: Raise the drain tubing to vertical position as shown in
Figure 2-6. Drain valve should be tilted up.
3. Open drain valve. Allow pump inlet tubing to fill with water (5-10 sec.).
4. See Figure 2-7 below. While trying not to spill, slowly lower drain tubing to
allow tubing to fill with water as shown. Fill as much as possible.
5. Close drain valve.
6. Again lift drain tubing to vertical position (see Figure 2-6 above).
7. While holding drain tubing vertical, open drain valve for 5 seconds.
8. Repeat above steps #4 (SLOWLY lower drain tubing …) through #7.
9. Close drain valve.
10. With valve closed dispense residual water from drain tubing into a bucket.
11. Turn on TCS power and run TCS for 15 seconds. (Power switch is on upper
rear panel of TCS.) If priming is successful, water should flow rapidly from
bath inlet within 15 seconds. If not, turn off TCS immediately and go back
to step #7, "Raise Drain Tubing".
12. Re-check the instrument level again (see Figure 2-2) with water in the bath.
Adjust leveling feet if necessary.
13. Tighten the locking nuts on each leveling foot.
14. Check all fittings for leaks for next five minutes.
